ASUS B860M MAX GAMING AX

Modern Intel Platform

Intel B860 · LGA1851

A modern Micro-ATX motherboard designed for Intel Core Ultra Processors (Series 2), providing a strong platform for gaming and advanced PC builds.

Robust Power Design

6(80A) + 1(80A) + 1(80A) + 1(80A) Power Stages

A strong power delivery solution with enlarged VRM heatsinks helps maintain stable performance under demanding workloads.

High-Speed DDR5 Memory

4 × DIMM · Up to 256GB

Supports DDR5 memory speeds up to 8666+MT/s OC, with Dual Channel, XMP, and AEMP III support.

Next-Generation Graphics Support

PCIe 5.0 x16

A primary PCIe 5.0 x16 slot with SafeSlot provides strong support for modern graphics cards.

Additional Expansion

PCIe 4.0

Multiple PCIe 4.0 expansion slots provide flexibility for additional hardware and add-in cards.

Ultra-Fast Storage

3 × M.2

Three M.2 slots include PCIe 5.0 x4 and PCIe 4.0 connectivity for high-speed NVMe storage.

Additional Storage

4 × SATA 6Gb/s

Four SATA ports provide flexible expansion for additional SSD and HDD drives.

Fast Wireless Networking

WiFi 6

WiFi 6 provides stable wireless connectivity with lower latency for gaming and everyday use.

High-Speed Wired Networking

Realtek 2.5Gb Ethernet

2.5Gb Ethernet delivers fast and reliable wired connectivity for gaming, streaming, and file transfers.

Ultra-Fast USB

USB Type-C 20Gbps

A USB Type-C port with speeds up to 20Gbps provides fast data transfer for modern devices.

DisplayPort over USB-C

Up to 4K 120Hz

The USB Type-C port supports DisplayPort video output up to 4K at 120Hz.

DisplayPort Output

Up to 4K 60Hz

A dedicated DisplayPort output supports resolutions up to 4K at 60Hz with a compatible processor.

Front USB Type-C

USB 10Gbps

A front-panel USB Type-C connector offers speeds up to 10Gbps.

Comprehensive Cooling

VRM + Chipset Heatsinks

Dedicated cooling solutions help maintain stable temperatures across key motherboard components.

AIO Cooling Support

AIO Pump Header

A dedicated AIO pump header and multiple fan headers provide flexible cooling options.

AI-Ready Features

AI Solutions

ASUS AI tools such as AI Advisor help simplify motherboard configuration and feature discovery.

Enhanced DDR5 Performance

AEMP III

ASUS AEMP III helps optimize DDR5 memory performance and tuning.

Comprehensive Protection

ASUS 5X Protection III

Includes DIGI+ VRM, ESD Guards, LANGuard, overvoltage protection, and other durability-focused features.

Easy PC Building

ASUS Q-Design

Features such as Q-DIMM, Q-LED Core, and Q-Slot simplify installation and troubleshooting.

RGB Customization

Aura Sync RGB

Supports Addressable Gen 2 RGB headers for synchronized lighting across compatible components.

Pre-Mounted I/O Shield

Easy Installation

A pre-mounted I/O shield simplifies installation while protecting rear connectivity ports.

Micro-ATX Form Factor

24.4 × 24.4 cm

A compact form factor that offers strong connectivity and expansion options for modern builds.
