GIGABYTE H610M H V2 DDR5 Intel LGA 1700 Motherboard

General Overview

This motherboard is an entry-level solution powered by the Intel H610 chipset, designed to support 12th, 13th, and 14th Generation Intel Core processors (LGA 1700 socket). Built on a Micro ATX form factor, it serves as a solid foundation for compact office PCs and budget gaming setups.

Processor and Chipset Support

Socket: LGA 1700

Supported Processors: Intel Core, Pentium Gold, and Celeron processors (12th, 13th, and 14th Gen)

Chipset: Intel H610 Express Chipset

System Memory

Memory Type: DDR5

Memory Slots: 2 x DDR5 DIMM slots

Maximum Capacity: Up to 64 GB

Architecture: Dual Channel Memory Architecture

Storage and Expansion Slots

Primary Graphics Slot: 1 x PCIe 4.0 x16 slot

Additional Expansion Slot: 1 x PCIe 3.0 x1 slot

M.2 Storage Slot: 1 x M.2 slot supporting PCIe 3.0 x4/x2 SSDs

SATA Storage Ports: 4 x SATA 6Gb/s connectors

Connectivity and Rear I/O Ports

LAN Connectivity: Realtek GbE LAN chip (1 Gbps) with bandwidth management

Display Output 1: 1 x HDMI port

Display Output 2: 1 x D-Sub (VGA) port

High-Speed USB Ports: 2 x USB 3.2 Gen 1 ports

Standard USB Ports: 4 x USB 2.0/1.1 ports

Legacy Port: 1 x PS/2 keyboard/mouse port

Network Port: 1 x RJ-45 LAN port

Audio Ports: 3 x High Definition Audio jacks powered by Realtek Audio Codec

Special Features and Cooling

Power Delivery: Hybrid 4+1+1 Phases Digital VRM Solution for stable power delivery

Cooling System: Smart Fan 6 featuring multiple temperature sensors and FAN STOP feature

Hardware Protection: Anti-Sulfur resistors and high-quality audio capacitors for durability
