hipset & CPU Support
Chipset: Intel® H610
Socket: LGA1700
Supported CPUs: 12th and
13th Gen Intel® Core™, Pentium® Gold, and Celeron® processors
Memory
Slots: 2 × DDR4 DIMM
Max Capacity: 64GB
Supported Speeds: DDR4 2133
/ 2400 / 2666 / 2933 / 3000 / 3200 MHz
XMP Support: Yes
Channel Architecture: Dual
Channel
Memory Type: Non-ECC,
Unbuffered
Graphics & Display
Outputs
Integrated Graphics:
Available with supported CPUs featuring integrated GPUs
Display Outputs:
1 × HDMI 2.0
Expansion Slots
PCIe x16 Slot: 1 × PCIe 4.0
x16
PCIe x1 Slot: 1 × PCIe 3.0
x1
Storage
M.2 Slots: 1 × M.2
2280/2260 (PCIe 3.0 x4/x2)
SATA Ports: 2 × SATA 6Gb/s
Audio
Audio Codec: Realtek® High
Definition Audio
Channels: 7.1-Channel HD
Audio
Networking
LAN: Realtek® Gigabit LAN
(1 Gbps)
Wi-Fi: Not supported
Bluetooth: Not supported
USB Connectivity
Rear I/O Ports:
2 × USB 3.2 Gen 1
4 × USB 2.0
1 × HDMI
1 × RJ-45 LAN
3 × Audio Jacks
Internal USB Headers:
1 × USB 3.2 Gen 1 Header (supports
2 additional ports)
1 × USB 2.0 Header (supports 2
additional ports)
Internal Connectors
1 × 24-pin ATX Power Connector
1 × 8-pin CPU Power Connector
1 × CPU Fan Header
1 × System Fan Header
1 × Front Panel Header
1 × Front Audio Header
1 × TPM Header
1 × Clear CMOS Jumper
Special Features
Anti-sulfur design for enhanced
durability
3+1+1 phase hybrid digital power
design with low RDS(on) MOSFETs
PCIe 4.0 ready PCB
High-quality audio capacitors
Audio noise guard design
Smart Fan 6 with temperature
sensors and fan stop functionality
Form Factor &
Dimensions
Form Factor: Micro ATX
Dimensions: 226 × 185 mm
