Chipset &
CPU Compatibility
Chipset: AMD B650
Socket: AM5
Supported CPUs: AMD
Ryzen™ 9000, 8000, and 7000 Series Desktop Processors
Memory
Memory Slots: 4 × DDR5
UDIMM
Maximum Capacity: 256GB
Memory Support:
DDR5 4800 MHz (JEDEC)
Overclocked (OC) support up to
DDR5 7200+ MHz
Supports AMD EXPO™ and Intel® XMP
memory modules
Dual-Channel Mode: Supported
Memory Types: Non-ECC,
un-buffered
Graphics &
Display
Integrated Graphics: Available
only with processors featuring integrated graphics
Video Outputs:
1 × HDMI™ 2.1 (up to 4K @ 60Hz)
1 × DisplayPort 1.4 (up to 4K @
60Hz)
Expansion Slots
PCIe x16 Slot:
Supports x16/x4 (for Ryzen™
9000/7000 Series processors)
Supports x8/x4 (for Ryzen™
8700/8600/8400 Series processors)
Supports x4/x4 (for Ryzen™
8500/8300 Series processors)
PCIe x1 Slots:
2 × PCIe 3.0 x1 slots
Storage
M.2 Slots:
2 × M.2 2280/2260 slots (supports
PCIe 4.0 x4)
SATA Ports:
4 × SATA 6Gb/s ports
RAID Support:
RAID 0, RAID 1, and RAID 10 for
SATA storage devices
Audio
Audio Codec: Realtek®
ALC897
Networking
& Connectivity
LAN: Realtek®
RTL8125BG 2.5Gbps LAN
Wireless LAN:
Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports MU-MIMO TX/RX
Supports 20MHz, 40MHz, 80MHz,
160MHz bandwidth in 2.4GHz/5GHz/6GHz bands
Bluetooth: Bluetooth®
5.3
USB Ports
Rear I/O:
4 × USB 2.0 Type-A
3 × USB 10Gbps Type-A
1 × USB 10Gbps Type-C
Front Panel:
2 × USB 5Gbps Type-A
1 × USB 10Gbps Type-
Internal I/O
Ports
Power Connectors:
1 × ATX_PWR
2 × CPU_PWR
Fan Headers:
1 × CPU Fan
1 × Pump Fan
3 × System Fan
Front Panel Connectors:
2 × Front Panel (JFP)
1 × Chassis Intrusion (JCI)
1 × Front Audio (JAUD)
Other Headers:
1 × Tuning Controller (JDASH)
2 × Addressable V2 RGB LED
(JARGB_V2)
2 × RGB LED (JRGB)
1 × TPM pin header (supports TPM
2.0)
Additional
Features
EZ Debug LED: 4 LEDs
for easy troubleshooting
Flash BIOS Button: Allows
BIOS updates without installing a CPU, memory, or graphics card
Physical
Dimensions
Form Factor: Micro ATX
(mATX)
Dimensions: 243.84 mm
× 243.84 mm
